This is a great opportunity to buy a fully functioning, nearly new product at a discounted price, supplied with a two year warranty
Utilizing custom dbx mu-metal-shielded audio transformers, high-quality Neutrik connectors, and low-noise circuitry preserves the sonic integrity and true characteristics of the signal source. Both boxes include a pad switch that accommodates instrument, line and even speaker level signals. Take even more control of your sound by utilizing the polarity invert switch to set the phase relationship between the direct and mic'd sound.
As a professional, you don't have time for interference, so we've included a ground lift switch to solve potential hum and buzz problems due to ground loops. And between the combined shielding of the cast metal chassis and the custom-wound transformer, you can be doubly assured of a clean signal free from interference. All of this sits atop a solid, stable footprint, that will keep the box from being dragged around the stage, and the unique contoured underside allows secure stacking of multiple units.
Features
- Premium Performance
- Rugged Design
- Stackable Chassis with Durable Rubber Foot
- Gold-plated Neutrik XLR Connector
- Premium Chrome Toggle Switches
- Hi-Z 1/4" Input Jack
- Parallel 1/4" Thru Jack
- Transformer Isolated
- Premium Shielded Custom dbx Transformer
- Balanced XLR Lo-Z Output
- 3-Way 0/20/40 dB Pad Switch
- Flat/High-Cut Filter Switch
- Output Polarity Invert Switch
- Ground Lift Switch
- Phantom Powered
- Green LED Phantom Power Indicator
- +48V Phantom Operation
- Low-Noise Active Circuitry
Specifications
INPUT SECTION
- Input: 1 instrument/line/speaker level
- Connector: 1/4" jack
- Type: Unbalanced, RF filtered
- Impedance: 1M Ohm (0dB pad), 47k Ohm (20dB pad), 47k Ohm (40dB pad)
- Max Input Level: +10dBu (0dB pad), +30dBu (20dB pad), +50dBu (40dB pad)
OUTPUT SECTION
- Thru Output: 1 parallel connection from input jack
- Connector: 1/4" jack
- Type: Unbalanced, RF filtered
- Main Output: 1 line level
- Connector: XLR male jack
- Type: Balanced
- Impedance: 150 Ohm typical
- Max Output Level: +8dBu into 600 Ohm
PERFORMANCE
- Transformer: Custom dbx mu-metal-shielded
- Frequency Response: 20Hz to 20kHz, +/-3dB
- 30Hz to 20kHz, +0/-1dB
- Noise: <-105dB unweighted, 22kHz BW
- THD: <0.01 , 20Hz to 20kHz BW, <0.005 , 1kHz, 0dBu output
Please Note
Second hand products will be shipped boxed, however, we can not guarantee this will be delivered with the manufacturers original packaging; otherwise, the unit itself operates as new.
Cosmetic Damage
- Second hand products may have slight scratches to the casing
