Record more sources at once
The UMC1820 provides 18 inputs and 20 outputs, giving you plenty of flexibility when recording multiple performers or hardware devices. Eight combination XLR/TRS inputs let you connect microphones, instruments, and line-level equipment simultaneously, while dedicated MIDI I/O makes it easy to integrate controllers, drum machines, and other MIDI hardware. Whether you're tracking a full drum kit, recording a rehearsal session, or managing a larger project studio setup, the available connections help keep everything organised and ready to record.
Capture detail with Midas preamps
At the heart of the UMC1820 are eight Midas-designed microphone preamps. Known for their transparent and detailed performance, these preamps help preserve the character of your microphones and sources. Combined with professional 24-bit/96kHz converters, the interface captures recordings with the resolution needed for music production, podcasting, and post-production work. Plus, selectable phantom power allows you to use condenser microphones when a project calls for extra sensitivity and detail.
Monitor without distracting delay
Recording performances feels more natural when monitoring is immediate. The UMC1820 features zero-latency direct monitoring, allowing performers to hear their input signal without waiting for it to pass through software. This can help improve timing and confidence during recording sessions. Two dedicated headphone outputs, each with independent level control, make it easy to create monitoring arrangements for different performers, while Monitor A/B source selection supports cueing and playback management.
Expand your studio as you grow
The UMC1820 is designed to adapt to changing recording needs. ADAT connectivity allows expansion with compatible units such as the ADA8200, increasing the available microphone inputs for larger sessions. Support for S/PDIF, ADAT, S/MUX, and analogue connections means the interface can fit into a wide range of studio environments. USB 2.0 connectivity provides straightforward integration with Mac and Windows computers, and compatibility with popular recording software helps streamline your workflow from the start.
Features
- 18 x 20 USB2.0 audio/MIDI interface with ADAT I/O
- Audiophile 24-bit/96kHz resolution
- Compatible with variety of popular recording software
- Streams 18 inputs & 20 outputs of ultra-low latency audio to a computer
- 8 state-of-the-art mic preamplifiers with +48V phantom power
- Optical I/Os supporting S/PDIF, ADAT & S/MUX formats up to 96kHz
- Simultaneous use of all analog, coaxial S/PDIF, optical ADAT & MIDI signals
- Zero-latency direct monitoring of all analog inputs whilst recording
- Input/playback mix control & stereo/mono switch
- Powerful dual phones outputs with individual level controls & monitor A/B source select
- Main outputs with dim, mute & dedicated main level control
- Free audio recording, editing & podcasting software with 150 instrument/effect plug-ins at Behringer.com
- 19'', 1U cabinet with detachable rack mount brackets
- Impact resistant metal chassis
Specifications
- Preamps: 8 x MIDAS Designed
- Input Type: XLR/TRS Combo Connector (Mic/Line/Instrument), 2 Front/6 Rear
- Input Level Attenuation: 8 x Pad Switch
- Frequency Response: 10Hz - 85kHz (+0/-3 dB) / Direct Monitor
- Impedance: Mic In 3kΩ, Instrument In 1MΩ
- Max Input Level: Mic 11 dBu, Line 11 dBu, Instrument 18 dBu
- Phantom Power: +48 V Switchable Inputs 1-4 and 5-8
- Outputs: 8 x 1/4'' TRS Line Outputs, 2 x 1/4'' TRS Main Outputs, 2 x 1/4'' TRS Stereo Headphone Outputs
- Max Output Level: +16 dBu Line Outputs, +16 dBu Main Outputs, +21.5 dBu Headphone Outputs
- Dynamic Range: 106 dB, A-Weighted
- System Freqeuncy Response: 10Hz - 40kHz @ 96kHz Sampling Rate
- Digital Audio I/O
- Coaxial: RCA - 1 In, 1 Out
- Optical: TOSLINK - 1 In, 1 Out
- Supported Formats: ADAT, S/PDIF, S/MUX
- MIDI I/O: 5-Pin DIN, 1 In / 1 Out
- Monitoring
- Direct Monitor Control: Mix Control, Source Select, Stereo/Mono Select
- Main L/R Control: Output Level 1/L - 2/R Control, Dim and Mute Switch
- Headphones DJ Cueing: Monitor Switches (Monitor Mix 1-2 / Playback Out 3-4)
- Digital Processing
- Converter Resolution: 24-Bit
- Supported Sample Rates: 44.1, 48, 88.2, 96kHz
- Digital I/O Routing
- S/PDIF Selected (OPT I/O Switch Out)
- RCA In: Off
- Optical In: S/PDIF (Channel 9-10)
- RCA Out and Optical Out: S/PDIF (Channel 11-12)
- ADAT Selected
- RCA In: S/PDIF (Channel 9-10)
- Optical In @ 96 / 88.2kHz: S/MUX (Channel 11-14)
- Optical In @ 48 / 44.1kiHz: ADAT (Channel 11-18)
- RCA Out: S/PDIF (Channel 11-12)
- Optical Out @ 96 / 88.2kHz: S/MUX (Channel 13-16)
- Optical Out @ 48 / 44.1kHz: ADAT (Channel 13-20)
- Computer BUS Connectivity: USB 2.0, Type B
- Compatible Operating Systems: Windows XP and Higher, Mac OS 10.9 and Higher
- Drivers
- Mac: No Driver Required
- Windows: 2 Drivers Available From Behringer.com
- Voltage: 12 V DC
- Power Consumption: 20W
- Weight: 1.8 kg
- Dimensions
- Height: 46 mm
- Width: 483 mm
- Depth: 130 mm
