Manley CORE Mic-Pre, EQ, Compressor & FET Limiter
Manley CORE Mic-Pre, EQ, Compressor & FET LimiterDetails
Product Ref: 75880View Full Description
Buy on finance from £51.20 per month Finance from £51.20 per month
Please note: This is only available where all items in the order are dispatched in a single delivery.
To make it as easy as possible for you to get the gear you want, we offer a range of instant finance options. If you spend £250 or more online, you can choose to pay over 48, 36 or 24 months. The majority of decisions are given instantly, so you could get your new gear sooner than you thought!
To help you understand how our finance options work, the examples below are based on a total order value of £250:
|Finance||APR||Deposit to Pay||Payments||Total Payable|
|Classic Credit 48 Months 14.9%||14.9%||No Deposit||48 months: £6.83 |
Final payment: £6.83
No settlement fee
|Classic Credit 36 Months 15.9%||15.9%||No Deposit||36 months: £8.65 |
Final payment: £8.65
No settlement fee
|Classic Credit 24 Months 18.9%||18.9%||No Deposit||24 months: £12.41 |
Final payment: £12.41
No settlement fee
How to Apply
Applying for finance couldn't be easier - if your order totals £250 or more, simply proceed through the checkout as normal, then select Pay by Finance on the payment page, then click the orange APPLY FOR INSTANT FINANCE button. This will start your application with V12 Retail Finance, our finance partner, and completing this form should take approximately 10 minutes.
You should get an instant answer on whether your application has been successful, though in some rare cases V12 may need to look at the application in more detail.
Please note: This is only available on orders placed via the website consisting of a single delivery, and is not available in store or via phone currently.
Full DescriptionView Full Description
The Manley CORE Mic-Pre, EQ, Compressor & FET Limiter utilises a simple, yet effective front panel interface. You get a high-end Manley mic preamp, followed by a 3:1 ELOP style compressor putting you in complete control of dynamics. The active Baxandall EQ gives you full access to equalisation parameters and a fast attack FET brickwall prevents your converters from accidental clipping.
The CORE features direct inputs to the widely renowned Manley IRON, allowing for the clearest, most accurate audio from your recording devices. The tube amplifying stage features technology taken from the Manley VOXBOX, implementing huge headroom and high output drive capability.
¼” Direct Input
The Manley CORE Mic-Pre, EQ, Compressor & FET Limiter boasts a solid-state circuit with 10 Meg Ohm input impedance, very similar to that in the Manley SLAM!, making the CORE perfect for guitars, bass, keyboards, etc.
- Easy to use and awesome-sounding channel strip based on the award-winning VOXBOX
- Class A tube mic preamplifier with Manley's hand-wound transformers
- Direct input uses the same circuit as the Manley SLAM! for fantastic direct-instrument recordings
- ELOP compressor with 3:1 ratio tames any signal transparently
- Baxandall EQ with low/high shelving and sweepable mid for flexible sonic sculpting
- Fast attack FET brickwall limiter ensures you don't clip your converters during recording
- Flexible metering can display input, output, and compressor gain reduction levels
- Balanced Transformer Coupled XLR Microphone Input Impedance: 1200 Ohms
- Balanced XLR Line Input Impedance: 10 kOhms
- Unbalanced 1/4" Direct Input Impedance: 10 Meg Ohm
- Hi-current drive Direct XLR output Impedance: 50 Ohms
- Compressor Maximum GAIN REDUCTION: 16 dB
- Compressor ATTACK time: 60ms slowest CCW, 30ms at 12:00, 5ms fastest CW for 6dB compression
- Compressor RELEASE time: 1.5s slowest CCW, 1s at 12:00, 100ms fastest CW from 6dB compression
- Insert Send output impedance: 50 Ohms
- Insert Return input impedance: 13 kOhms
- Main Output Impedance: 50 Ohms
- Direct Output Headroom (referenced to +4 dBv): 31 dB
- Main Output Headroom (referenced to +4 dBv): 16 dB
- Dynamic Range: >90 dB
- Frequency Response: 10 Hz to 20 kHz ±0.5 dB
- THD & Noise (1kHz @ +4 dBm): 0.02% at Low Gain setting
- Noise Floor (Gain set to minimum): -70 dB wideband typical
- Gain via Microphone Input: 40 or 60 dB
- Gain via Line Input: 20 or 40dB
- Maximum Gain of EQ & Limiter section: 10 dB
- AUTOMUTE warmup delay: 30 Seconds
- Power consumption: 35 watts
- Operating mains voltage: 90 to 254 VAC (internal universal supply)
- Mains Voltage Frequency: 50-60Hz
- Dimensions: 19" x 3 1/2" x 7" (occupies 2u)
- Unit Weight: 8.3 lbs.
- Shipping weight: 11.5 lbs.
- Maximum Mic Input
- Low Gain Setting): -5 dBu or 435mV RMS @ 0.5% THD
- High Gain Setting): -25 dBu or 44 mV RMS @ 0.5% THD
- Maximum Line Input
- Maximum Input Line input (Low Gain Setting): +13 dBu or 3.5V RMS @ 0.5% THD
- Maximum Input Line input (High Gain Setting): -8 dBu or 300mV RMS @ 0.5% THD
- Maximum Direct Input
- Maximum Input Direct input (Low Gain Setting): +24 dBu or 12V RMS @ 0.5% THD
- Maximum Input Direct input (High Gain Setting): +17 dBu or 5.5V RMS @ 0.5% THD
- Maximum Input Insert return
- Maximum Input Insert return: +20 dBu or 7.8V RMS @ 0.5% THD
- Maximum Preamp Output
- (Insert Send): +35 dBu or 43V RMS @ 0.5% THD
- Maximum Preamp Output (Insert Send): +22 dBu into 600 Ohms
- Maximum Main Output
- Maximum Main Output: +20 dBu
- 48V Phantom power switch
- 120Hz High Pass Filter switch
- Phase Invert switch
- Input Attenuator (Variable Pad)
- Mic Pre Selectable Gain 40dB or 60dB
- Line Amp Selectable Gain 20dB or 40dB
- Similar to the DI in the Manley SLAM!, this all-discrete solid-state circuit with 10 Meg Ohm input impedance is perfect for guitars, bass, keyboards, etc.
- Featuring our successful ELOP technology also found in our famous Manley VOXBOX®
- Compressor is uniquely before the Mic Preamp making it virtually impossible to clip
- Ratio 3:1
- Continuously variable Attack, Release, and Threshold controls
- Silent Bypass switch
- Low and High Baxandall Shelves (80Hz and 12kHz) with ±12dB range
- Sweepable Midrange Bell EQ (100Hz – 1kHz) or (1kHz – 10kHz) with ±10dB range
- Fast attack FET “brickwall” limiter
- Continuously Variable Threshold and Release controls
- Peak Limit LED indicator
- 10dB range output gain control
- Large illuminated analog display
- 3-way meter-select switch shows Compressor Gain Reduction, Micpre Output Level, and Main Output audio levels.
- Balanced XLR Mic Input
- Balanced XLR Line Input
- Front Panel Direct Instrument 1/4" Input
- Insert point between Mic Preamp and EQ/Limiter via ¼” TRS jack
- Balanced XLR Direct Output (after Preamp/Compressor section)
- Balanced XLR Main Output
- Deluxe CNC-machined 1/4" thick faceplate with inlaid laser-engraved inserts adorn the rigid 2U steel chassis – all locally sourced in Southern California.
