Chauvet DJ FXPAR6 RGBW FX Wash

Full Description

Create layered wash and ring effects

This fixture combines 18 quad-colour RGBW LEDs with a separate RGB outer ring, letting you control the centre wash and outer ring independently. You can build bold colour fills while adding movement or contrast around the edge. It’s a practical way to make small rigs look more involved, without adding extra fixtures. Whether you’re lighting a DJ booth, stage backdrop, or dancefloor, the dual-source design gives you more variety from a single unit.

Shape your show with six zones

Six-zone control opens up more detailed programming, especially when using DMX. Instead of a single block of colour, you can split the fixture into sections and create chases, pulses, and layered effects that feel more dynamic. Choose between 3, 6, or 11 DMX channels to match your setup and experience level. If you’re running a compact controller, it’s flexible enough to fit in without taking over your entire universe.

Quick setup with flexible control

Built-in automated and sound-activated programmes help you get up and running quickly. This is ideal for mobile DJs and small venues where time is tight. If you prefer hands-on control, the fixture works with standard 3-pin DMX and supports the optional IRC-6 remote for adjusting colours and programmes without a desk. Power linking lets you connect multiple units together — cutting down on spare sockets and trailing leads.

Compact build with reliable output

Despite its small footprint, the unit produces a strong output with a 20° beam angle and a 36° field angle, making it suitable for focused washes and mid-sized spaces. Flicker-free operation keeps your lighting consistent for video work, so it won’t cause issues on camera. With a lightweight housing and integrated bracket, it’s easy to mount on truss or position on the floor, and it fits neatly into the CHS-40 VIP Gear Bag for transport.

Features

• Compact multi-effect par with dual light sources
• Independent RGBW wash and RGB ring control
• Six zones for detailed lighting effects
• Built-in sound and automatic programmes
• Optional IRC-6 remote compatibility
• Power link multiple units together
• Flicker-free output for video use
• Fits CHS-40 VIP Gear Bag

Specifications

• DMX Channels: 3, 6, or 11
• DMX Connectors: 3-pin XLR
• Light Source (Wash): 18 RGBW LEDs, 52 W, 50,000 hours life expectancy
• Light Source (Ring): 51 RGB LEDs, 6 W, 50,000 hours life expectancy
• Strobe Rate: 0 to 20 Hz
• Beam Angle: 20°
• Field Angle: 36°
• Illuminance: 5,657 lux @ 2 m
• Lumens: 3,239
• Power Linking: 8 units @ 120 V; 12 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power And Current (120 V): 63 W, 0.9 A @ 120 V, 60 Hz
• Power And Current (230 V): 62 W, 0.6 A @ 230 V, 50 Hz
• Bracket Mounting Hole: 13 mm
• Dimensions (W x D x H): 275 mm x 69 mm x 305 mm
• Weight: 1.3 kg
• Approvals: CE, RoHS
