DISC Audio Technica ATM350 Condenser Clip Microphone

£244.00 RRP £291.00 (including VAT @ 20%)

This product is currently not available for purchase

DISC Audio Technica ATM350 Condenser Clip Microphone

Details

Supplied with Audio-Technica's versatile UniMount clip and new violin mount, the low-profile ATM350 is an exceptional cardioid condenser microphone designed to clip to brass, reeds, piano, snare, toms, and violin.

Product Ref: 19082

View Full Description

Full Description

View Full Description

The microphone offers a crisp, clear, well-balanced response, even at high SPLs. It features an integral 80 Hz hi-pass filter and is also equipped with a new in-line power module. Its cardioid polar pattern reduces pickup of sounds from the side and rear for effective protection against feedback.

The ATM350 is intended for use in professional applications where remote power is available. It requires 11V to 52V DC phantom power, which may be provided by a mixer or console, or by a separate, in-line source such as the Audio-Technica AT8801 singlechannel or CP8506 four-channel phantom power supplies.

An integral 80 Hz high-pass filter provides easy switching from a flat frequency response to a low-end roll-off. The roll-off position reduces the pickup of low-frequency ambient noise (such as traffic, air-handling systems, etc.), room reverberation and mechanically coupled vibrations.

Output from the power module's XLRM-type connector is low impedance (Lo-Z) balanced. The signal appears across Pins 2 and 3; Pin 1 is ground (shield). Output phase is "Pin 2 hot" - positive acoustic pressure produces positive voltage at Pin 2. To avoid phase cancellation and poor sound, all mic cables must be wired consistently: Pin 1-to-Pin 1, etc.

To use the violin mount, place the microphone in the violin mount's elastic mic holder. Open the hook & loop fastener; pass the hook side of the open fastener beneath the strings between the bridge and the tailpiece. Close the fastener flap around the strings. The microphone should be on top, with the element facing the bridge (away from the tailpiece).

Features/Specifications:

  • Low-profile design for minimum visibility
  • UniMount® clip permits accurate positioning, provides shock resistance and protects element
  • Unique violin mount permits unobtrusive placement of microphone between the instrument's bridge and tailpiece
  • Crisp, clear, well-balanced response, even at high SPLs
  • Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
  • Interchangeable elements available for hypercardioid and omnidirectional polar patterns
  • Corrosion-resistant contacts from gold-plated XLRM-type connector Rugged, all-metal design and construction for years of trouble-free use

Further Specs:

  • Element: Fixed-charge back plate permanently polarized condenser
  • Polar Pattern: Cardioid
  • Frequency Response: 40-20,000 Hz
  • Low Frequency Roll Off: 80 Hz, 12 dB/octave
  • Open Circuit Sensitivity: 49 dB (3.5 mV) re 1V at 1 Pa
  • Impedance: 50 ohms
  • Maximum Input Sound Level: 149 dB SPL, 1 kHz at 1 T.H.D.
  • Dynamic Range: 122 dB, 1 kHz at Max SPL
  • Signal to Noise Ratio: 67 dB, 1 kHz at 1 Pa
  • Phantom Power Requiremens: 11-52V DC, 3.5 mA typical
  • Switch: Flat, roll-off
  • Cable: 4.0 m (13.1') long (permanently attached to microphone), 3.2 mm (0.13") diameter, 2-conductor shielded cable with TA3F-type connector

Accessories:

  • Soft protective pouch
